Tool&Die super subdural ion plating machine

This equipment is designed for coating hard or super-hard protective films on tools, knives and molds. The vacuum seal of the vacuum coating chamber and the design and materials of the moving parts in the chamber are fully considered to withstand high temperatures. It is equipped with multiple high-efficiency circular arc evaporation sources, or multiple rectangular plane arc evaporation sources, or multiple hollow cathode guns. At the same time, it is equipped with a bias power supply that is impact-resistant and has flash arc extinguishing performance to ensure sufficient plasma density and reaction activity and improve the density and bonding strength of the film layer. The workpiece can move in three dimensions to improve the uniformity of the film layer. Fully automatic control improves process stability. It can be plated with TIN, TIC, TICN, TIAIN, TIAICN, TICrN, TICrCN, TIAICIN, multi-layer super-hard films, etc., and is used in the precision mold industry (stamping molds, shearing molds, standard parts molds, forming molds, etc.), tool industry (drills, carbide, milling cutters, broaches, taps and gear tools, etc.), and the automotive industry (pistons, piston rings, alloy wheels, etc.).

PREV：No previous product NEXT：Tools PVD hard surface coating machine

Product Description

System Summary

Tools PVD Thin Film Deposition Vacuum Coating Machine is high performing and easy operating, equipped with arc sputtering system. This machine offers a wide range of application, such as hard film coating, abrasion resistance coating and exterior coating on tools of cutting, stamping, molding and metal die-casting, with DLC (diamond like coating) function to improve the hardness.
Substrates can be three-dimensional motion, to enhance the uniform of coating. The full automatic control processing is steady and perfect.

System Type

• Vertical Batch – Single or double door

Coating:

• TiN, TiC, TiCN, TiAlN, TiAlCN, TiCrN, TiCrN, TiCrCN, TiAlCrN and other multilayer super hard coatings.

APPLICATION:

• Precision mould industry: Stamping die, die cut, standard mold, etc.

• Tools industry: drill, milling head, broaches, gear cutters, etc.

• Auto industry: pistons, piston rings, alloy wheels, etc.

• Engine parts: non-ferrous metal cutting tools, non-ferrous metals and stainless steel forming stamping dies, sliding seal parts, injection molds, etc.

• Racing car parts: valve parts, piston accessories, hydraulic parts /suspension /gearbox.

• Auto car industry: chassis parts, brake components, engine parts, transmission parts.

• Medical technology.
